SKU : TX2
Specification Hardware: Standard&Protocol - IEEE802.3, IEEE802.3u,IEEE802.3ab Interfaces: - 1*10/100/1000Mbps WAN Port - 3*10/100/1000Mbps LAN Ports Antenna - 4*6dBi External Antennas Button - WPS/Reset Button*1 Power - Input：AC 100-240V~50/60Hz 0.6A - Output：DC 12V⎓1A LED Indicator - SYS*1 Dimension - 9.40*5.68*1.58 in (238.9*144.3*40.3mm) Wireless: Wireless Standard - IEEE 802.11n/b/g 2.4 GHz - IEEE 802.11ax/ac/n/a 5GHz Data Rate - 5GHz: Up to 1201Mbps - 2.4GHz: Up to 300Mbps Frequency - 2.4GHz & 5GHz Transmission Power - <20dBm(2.4G) - <23dBm(5G) Basic Features - Beamforming - MU-MIMO - Smart Power Saving - Tenda App: Local and Remote Management Wireless Security - WPA2-PSK - WPA3-SAE/WPA2-PSK - Wireless Encryption Disable and Enable - WPS Fast Connection Software: Internet Connection Type - PPPoE, Dynamic IP, Static IP - PPPoE(Russia), PPTP(Russia), L2TP(Russia) - Unify,Maxis,Maxis-special,Celcom,Digi Network Protocol Operating Mode - Wireless Router Mode - AP Mode - Universal Repeater Mode（Client+AP） DHCP - DHCP Server - DHCP Client List - DHCP Reservation Virtual Server - Port Forwarding - DMZ Host - UPnP Security - Parental Control - Client Filter Firewall - Forbid UDP Flood Attack - Forbid TCP Flood Attack - Forbid ICMP Flood Attack - Forbid WAN Ping from Internet DDNS - Support DynDNS, No-ip，oray，88ip Special Features - WPA3 - Unify 2.4 GHz & 5 GHz - Smart LED on/off - Tenda Wi-Fi App Other Function - Bandwidth Control - Guest Network - IPTV - VLAN - MAC Clone - Static Routing - System Log - Backup & Restore configurations - Firmware upgrade online - Firmware upgradeable via browser - Supports IPv6 Others Temperature - Operating Temperature : 0℃~40℃ - Storage Temperature : -40C ~70℃ Humidity - Operating Humidity : 10 %~90% RH non-condensing - Storage Humidity : 5 %~ 90%RH non-condensing Default Settings - tendawifi.com or //192.168.0.1 Certification - CE, RoHS, FCC EIRP Power (Max) - 2.4GHz＜20dBm - 5GHz＜23dBm Package Contents - Dual-Band Gigabit Wi-Fi 6 Router*1 - Ethernet Cable*1 - Power Adapter*1 - Installation Guide*1
